UB-108



USB 3.0 (NEC chipset) 5Gbps Low Profile PCIe Gen2 Host Adapter

USB 3.0 SuperSpeed 5Gbps in one Low Profile PCIe 2.0 Host Adapter to support all kind of 1.5Mbps, 12Mbps, 480Mbps and 5Gbps USB Devices!

FEATURES



o        USB 3.0 PCI Express 2.0 x1 Lane Host Adapter

o        Supports PCIe 1.0 and PCIe 2.0 motherboard

o        Compliant with Universal Serial Bus 3.0 Specification Revision 1.0

o        Compliant with Intel eXtensible Host Controller Interface (xHCI) Specification 1.0

o        Two USB 3.0 Type A downstream connectors on board

o        All USB ports can handle SuperSpeed (5 Gbps), HighSpeed (480 Mbps), FullSpeed (12 Mbps), and LowSpeed (1.5 Mbps) transaction

o        Support USB3.0, USB2.0 and USB1.1 devices

o        Compliant with PCI Express Specification 2.0

o        Low Profile PCIe Form Factor

o        Regular size PCIe bracket on card and additional Low Profile PCIe Bracket included

o        Supports Max 1.5A USB 5V bus power one USB 3.0 port

o        Provides 2Ports USB 3.0 power to USB devices from Motherboard PCIe slot directly, or from PC power supply if on board 15Pin SATA power connector connected

o        Windows 10, Win8, Server 2012, Linux kernel 2.6.31 and later OS in-box USB driver natively support UASP, no additional driver required

o        Provides Renesas 64bit and 32bit Windows 7, Vista, XP and 64bit 2008 R2 driver

o        Chipset : Renesas (NEC)

o        Fully RoHS compliant
