ST-208

SATA + 1394a Combo Low Profile PCI Host Adapter

Discontinued!

UB-201  Instead!
　

FEATURES

o        2 Ports SATA (1.5Gbps) and 3Ports 1394a (400Mbps) low profile PCI host interface

o        Compliant with PCI Specification revision 2.2, 32 bit, 33MHz

o        Integrated PCI DMA engine

o        Low Profile Form Factor

o  Provides Low profile PCI and Regular size PCI two brackets

o        Completely with drivers for 64bit / 32bit Windows 7, Vista, 2000, 2003 server, XP, 98, and ME

o        Linux kernel version of 2.4.18-14 or later has built-in driver support

o        Fully RoHS compliant

1. Serial ATA

o        Independent two ports Native Serial ATA

o        Serial ATA data rates 1.5Gbps

o        48 bits LBA can Break Capacity-Limit to Support HDD larger than 137GB

o        Fully compliant with Serial ATA 1.0a specifications

o        Supports Spread Spectrum in receiver

o        Independent 256-byte FIFOs (32 bit * 64 deep) per Serial ATA channel for host reads and writes

o        Chipset : SiliconImage

2. IEEE 1394 (FireWire 400)

o        Compliant with IEEE 1394 Open Host Controller Interface specification release 1.1 and IEEE Std 1394a-2000

o        Provides three 1394 ports (2 External 6Pin connectors+ 1 External 4Pin connector) at 100/200/400 Mbps

o        Built-in FIFOs for isochronous transmit (2048 bytes), asynchronous transmit (2048 bytes), and receive (3072 bytes)

o        32-bit CRC generation and checking for receive/transmit packets

o        On Board Molex mini 4Pin Power connector to have sufficient 1394 1.5A/12V bus power from PC power supply
