IO-114

RS232 4Ports Low Profile USB-Based Host Adapter (with DB9M 5V Bus Power)

Low Profile Adapter converts one USB host port to RS232 4Ports with DB9M 5V bus output power at baud rate 230Kbps!@

FEATURES

@

o        Four 16550 High performance UART (RS232) serial channels

o        Occupies one PCI or PCIe bus slot

o        Low Profile PCI Form Factor

o        Includes Low Profile PCI & Regular size PCI two brackets

o        Both USB A type and USB pin header connector on board to host connection

o        Includes one DB9M 4x Fan Out cable expansion to RS232 DB9M four ports

o        5VDC Power output from each DB9M Port for POS device use application

o        4 Jumpers Individually enable / disable 5VDC output for each DM9M Port

o        On Board Molex mini 4Pin Power connector for sufficient DB9M 5V bus power from PC power supply

o        Supports data transfer rate up to 230 Kbps

o        USB based UART controller, an available motherboard USB port is required

o        Supports 32bit/64bit Windows 7, Vista, XP, 2000, ME, 98SE

o        Fully RoHS compliant

@
