Please find Kouwell's brand product line that had been maintained and run by LyCOM from 1st July 2008.



  >>    HybridDrives Technology     PE-115H   PE-115m   <<



>>     Enjoy mSATA Technology with LyCOM Products    <<



**     LyCOM NVMe Products for M.2 & U.2 SSD    **



M.2 Key ID and LyCOM Various M.2 Product



The M.2 NGFF form factor is 75 Pins rectangular PCBA with an edge connector used for Mobile Add-In cards. Different M.2 module uses the different M.2 Key ID connector and has the different notched pin and signal interface, like below



1. M Key M.2 (Notched Pin 59-66) use on NVMe SSD





2. B Key M.2 (Notched Pin 12-19) use on SATA SSD or 3G/4G WWAN card





3. E Key M.2 (Notched Pin 22-31) use on WiFi card





For example, most mainboard only implement M.2 M Key socket, but due to the Key insertion prevention, user can’t install advanced popular E Key WiFi module into mainboard incompatible M Key host socket directly.



Recently more and more advanced and fast M.2 modules or SSD available in the market, so user actually need the vast type of M.2 converter board to enjoy M.2 new technologies on their PCIe mainboard, or mini-PCIe mainboard, or even different Key M.2 mainboard.





LyCOM M.2 Converter for PCIe or mini-PCIe or M.2 mainboard :



1. for NVMe SSD (M Key M.2)



(1-1)  PCIe mainboard use



DT-120



M.2 NGFF NVMe SSD to PCIe x4 4Lane Host Adapter





DT-125



1x NVMe + 2x  SATA Three 22110 M.2 SSD Low Profile PCIe 3.0 x4 Carrier Adapter







DT-129



PCIe x4 3.3V5A Host Adapter for M.2 NVMe 110mm SSD





DT-129A



PCIe x4 Carrier Adapter for M.2 NVMe 110mm High Power SSD







DT-130



Dual PCIe NVMe M.2 SSDs Carrier Adapter





(1-2)  M.2 mainboard use



DT-151M



NGFF M.2 M-Key to M-Key Riser Card







2.  for SATA SSD or 3G/4G WWAN card (B Key M.2)



(2-1)  PCIe mainboard use



PE-150B



M.2 B Key to PCIe Adapter for 3G 4G WWAN M.2 Module





(2-2)  mini-PCIe mainboard use



DT-134B



M.2 B Key to miniPCIe Adapter for 3G 4G WWAN M.2 Module





(2-3)  M.2 mainboard use



DT-151B



NGFF M.2 B-Key to B-Key Riser Card





3. for WiFi card or LAN card (E Key M.2)



(3-1)  PCIe mainboard use



PE-150E



M.2 E Key to PCIe Adapter for M.2 WiFi Module





(3-2)  mini-PCIe mainboard use



DT-134E



M.2 E Key to miniPCIe Adapter for M.2 WiFi Module







(3-3)  M.2 mainboard use



DT-150E



M.2 E Key to M Key Adapter for M.2 WiFi Module





LyCOM M.2 Module or Host Adapter



1. M Key M.2



DT-131



M.2 M Key Module with miniSAS HD 36P to U.2 NVMe SSD





DT-131U



M.2 M Key Module with miniSAS HD 36P (Upward) to U.2 NVMe SSD









DT-150E



M.2 E Key to M Key Adapter for M.2 WiFi Module



DT-151M



NGFF M.2 M-Key Riser Card











2. B Key M.2





DT-151B



NGFF M.2 B-Key Riser Card











3. B-M Key M.2





DT-139PM



Fast PCIe Base M.2 B-M Key Module to Micro SD 3.0





DT-152B



2x SATA 6Gbps M.2 NGFF Host Module







4. A-E Key M.2





NW-107



GigaLAN 1000BASE-T Ethernet PCIe x1 M.2 A-E Key Module





NW-107R



GigaLAN 1000BASE-T Ethernet PCIe x1 M.2 A-E Key Module (Right Angle RJ-45)





DT-139PA



Fast PCIe Base M.2 A-E Key Module to Micro SD 3.0







DT-137



RS232 M.2 A-E Key Module
