UB-105

　

USB 2.0 (NEC chipset) 5Ports Low Profile PCI Host Adapter

Discontinued!

ST-210 Instead!
　

FEATURES

　

1. PCI

　

o        Compliant with PCI Specification, revision 2.2

o        32 bit, 33MHz fully compliant PCI host interface

o        Low Profile PCI Form Factor

o        Integrated PCI DMA engine

　

2. USB 2.0

　

o        Provides Five USB2.0 ports (3 External + 2 Internal)

o        Includes 2 Brackets (Low Profile PCI and Regular size PCI Brackets)

o        5 USB Type A downstream connectors on board

o        Two additional USB 5Pin pin header shared with USB Type A internal connectors

o        Compliant with Universal Serial Bus Specification Revision 2.0 (Data Rate 1.5/12/480 Mbps)

o        Compliant with Open Host Controller Interface Specification for USB Rev 1.0a

o        Compliant with Enhanced Host Controller Interface Specification for USB Rev 0.95

o        All USB ports can handle high-speed (480 Mbps), full-speed (12 Mbps), and low-speed (1.5 Mbps) transaction

o        Windows and Mac Built-in drivers support

o        Chipset : NEC

o        Fully RoHS compliant
